MAVIG WD302

Movable radiation protection wall

Height adjustable mobile X-Ray Protective Shield WD302 effectively reduces the patient's scatter radiation from the body. The special design makes it easy to place it on the patient's body.

Easy to move
Vertical height adjustable
Markers
Shaped to ensure optimum protection

MAVIG WD302

Movable radiation protection wall

Height adjustable mobile X-Ray Protective Shield WD302 effectively reduces the patient's scatter radiation from the body. The special design makes it easy to place it on the patient's body.

Easy to move
Vertical height adjustable
Markers
Shaped to ensure optimum protection

WD261

WD204

WD304

WD257

WD260

WD300

WD302

WD306

WD504

WD258

Radiation protection for medical professionals

WD302:n yläosa koostuu läpinäkyvästä, muotoillusta lyijyakryylipaneelista, lyijyekvivalentti on 0,50 mm, 110 cm leveimmästä kohdasta.Alempi suojaosa koostuu teräsrungosta, jossa on harmaanvalkoinen, lakattu pinta (RAL 9002). Alaosan lyijyekvivalentti on 1,00 mm ja koko 78 cm x 78 cm (LxK).Yläosan korkeus on säädettävissä 143 cm:stä 190 cm:iin. Molemmissa tapauksissa mitat ovat suojan yläreunasta lattiaan.

Technical details of the model

Easy to steer, smooth wheels
Suitable for special intervention radiology applications
Height adjustable transparent top panel with lead acrylic 143-190 cm
Lead equivalent Pb of upper panel 0,50 mm
The bottom part of the frame consists of a steel body with lead equivalent Pb 1,00 mm
Steel frame piece lacquered in light (RAL 9002)

Dimensions

Steel sheet frame (Pb 1,00 mm): width 78 cm, height 78 cm
Height adjustable lead acrylic shield (Pb 0,50 mm): width 70 / 110 cm
Overall height: 143-190 cm
